Package
Standardized. Modular. Identical.
Our skilled experts fabricate, paint, and assemble each package entirely on our Sedalia campus. Every package is identical from one to the next with features that expedite installation, facilitate maintenance, and reduce noise.
100%
Made in the USA Enclosures
43.3 MW
Per Acre Energy Density
150
Packages Booked
INSTALLATION
Fast Track Your Project
Our package accelerates installation. We perform fit, form up, and alignment, as well as test entire electrical circuits, in the shop before the package ships to the field. Unloaded in a single lift, the package goes together without leaks or seams and with fewer input / output (I/O) points at the location.
EXHAUST SYSTEM
State of the Art Control
Our solution features built-in selective catalytic reduction (SCR) and carbon monoxide (CO) catalyst systems that cut NOx and CO emissions by 90 and 95 percent, respectively.
TOP OF STACK EMISSIONS
2.5
PPM
NOx
4.0
PPM
CO
10
PPM
NH3 Slip
FEATURES
Simplified Access and Care
Designed with user-friendly features, your package reduces service outage time, minimizes the physical footprint, and streamlines maintenance.
- Improved lighting. The main generator terminal box (MGTB) has enhanced visibility.
- Redesigned main turbine terminal box (MTTB). The shop can test entire circuits, and crews can reduce field connections from approximately 70 to 17.
- Improved turbine base layout. Maintenance technicians have enhanced accessibility.
- Single volute access door. Entry and work is easier without two separate hatches.
- Sectioned floor maintenance panels. A single worker can safely lift sections in the generator base.
